Subaru Legacy Owners Manual: Multi information display

WARNING Always pay adequate attention to safe driving when operating the multi information display while the vehicle is in motion. When operation of the multi information display interferes with your ability to concentrate on driving, stop the vehicle before performing operations on the screen. Also, do not concentrate on the display while driving. Doing so may cause you to look away from the road and could result in an accident.

Various information will be shown on the multi information display. Also, a warning message will appear on the display if a malfunction, etc. is detected. In addition, several settings for the displayed content can be performed.

Multi information display
Multi information display

  1.  ECO gauge (refer to "ECO gauge"  12.)
  2.  Basic screen/Warning screen (refer to "Basic screens"  and "Warning screen" .)
  3.  Cruise control information display
  4.  Select lever/gear position indicator (refer to "Select lever/gear position indicator" .)
  5.  Telltale screen (refer to "Telltale screen" .)
  6.  Odometer (refer to "Odometer" .)/ double trip meter (refer to "Double trip meter" .)

Control switch
Control switch

  1.  Up (select)
  2.  Set (enter)
  3.  Down (select)
Outside temperature indicator
U.S. spec. models  Except U.S. spec. models The outside temperature indicator shows the outside temperature in a range from −22 to 1228F (−30 to 508C). The indicator can give ...

Basic operation
By operating " " or " " of the control switch, the screens and selection items can be switched. When the " /SET" switch is pulled toward you, the item can be selected and set. If there are so ...
