AD22 | 10 |
| A-1 | i276 | Instrument panel wiring harness (sedan model) |
10 |
| C-1 | i276 | Instrument panel wiring harness (outback model) |
AD23 | 8 |
| A-2 | | Telematics button (sedan model) |
8 |
| C-2 | | Telematics button (outback model) |
AN1 | 3 |
| A-2 | | Audio (sedan model without navigation) |
3 |
| C-2 | | Audio (outback model without navigation) |
3 |
| A-2 | | Navigation unit (sedan model with navigation) |
3 |
| C-2 | | Navigation unit (outback model with navigation) |
AN2 | 1 | L | A-2 | | Audio (sedan model without navigation) |
1 | L | C-2 | | Audio (outback model without navigation) |
1 | L | A-2 | | Navigation unit (sedan model with navigation) |
1 | L | C-2 | | Navigation unit (outback model with navigation) |
AN3 | 3 |
| A-2 | AN4 | Antenna cord (sedan model without satellite antenna) |
3 |
| C-2 | AN4 | Antenna cord (outback model without satellite antenna) |
3 | L | A-2 | AN4 | Antenna cord (sedan model with satellite antenna) |
3 | L | C-2 | AN4 | Antenna cord (outback model with satellite antenna) |
AN4 | 3 |
| A-2 | AN3 | Antenna cord (sedan model without satellite antenna) |
3 |
| C-2 | AN3 | Antenna cord (outback model without satellite antenna) |
3 | L | A-2 | AN3 | Antenna cord (sedan model with satellite antenna) |
3 | L | C-2 | AN3 | Antenna cord (outback model with satellite antenna) |
AN7 | 3 |
| C-4 | AN9 | Antenna cord (without telematics without satellite antenna) |
3 | L | C-4 | AN9 | Antenna cord (without telematics with satellite antenna) |
3 | L | C-4 | AN9 | Antenna cord (with telematics) |
AN9 | 3 |
| D-4 | AN7 | Antenna cord (without satellite antenna) |
3 | L | D-4 | AN7 | Antenna cord (with satellite antenna) |
AN10 | 1 |
| D-4 | R407 | Rear wiring harness LH |
AN11 | 3 |
| C-4 | AN15 | Antenna |
AN12 | 1 | V | C-4 | AN16 | Antenna (sedan model) |
1 | Gr | C-4 | AN16 | Antenna (outback model) |
AN14 | 3 |
| B-3 | AN17 | Antenna |
AN15 | 3 |
| C-4 | AN11 | Antenna cord |
AN16 | 1 | V | C-4 | AN12 | Antenna cord (sedan model) |
1 | Gr | C-4 | AN12 | Antenna cord (outback model) |
AN17 | 3 |
| B-3 | AN14 | Antenna cord |
AN18 | 2 |
| B-3 | R97 |
AN31 | 1 | V | A-2 | AN32 | Antenna cord (sedan model) |
1 | V | C-2 | AN32 | Antenna cord (outback model) |
AN32 | 1 | V | A-2 | AN31 | Antenna cord (sedan model) |
1 | V | C-2 | AN31 | Antenna cord (outback model) |
AN33 | 4 |
| A-1 | AN34 | Antenna cord (sedan model) |
4 |
| C-1 | AN34 | Antenna cord (outback model) |
AN34 | 4 |
| A-1 | AN33 | Antenna cord (sedan model) |
4 |
| C-1 | AN33 | Antenna cord (outback model) |
AN35 | 2 | V | B-3 | AN36 | Antenna cord (sedan model) |
1 | L | C-3 | AN36 | Antenna cord (outback model) |
AN36 | 2 | V | A-3 | AN35 | Antenna cord (sedan model) |
1 | V | D-4 | AN35 | Antenna cord (outback model) |
AN37 | 1 | V | A-3 | AN38 | Antenna |
AN38 | 1 | V | A-4 | AN37 | Antenna cord |
AN39 | 1 | V | A-3 | AN40 | Antenna |
AN40 | 1 | V | A-3 | AN39 | Antenna cord |
AN41 | 1 | Br | A-2 | | Data communication module (sedan model) |
1 | Br | C-2 | | Data communication module (outback model) |
:White or natural color |
Audio system wiring diagram
